Stainless steel electrode suitable for welding dissimilar steels, also used for tough buffer layers in hard surfacing where hot and warm deformation exist and takes place.
Features and Applications
Unalloyed and low alloyed hard to weld steels with higher carbon content as well as heat treatable steels and tool steels, Mn steels, joining dissimilar steels, used for tough buffer layers in hard surfacing where hot and warm deformation exist are take place
Requirement of re-drying for min. 2 hours at temperatures of 300°C
Uses in welding of Chromium/Manganese steels tools steels, unalloyed and alloyed high-strength steels
Typical Base Material Grades
Uses in welding of Chromium-/Manganese-steels, tool steels, unalloyed and alloyed high-strength steels.
Standards Current Type
EN ISO 3581-A - E Z 29 9 R 12
D.C. (+) / A.C.
AWS A5.4 - E 312-17
Chemical Composition of Weld Metal % (Typical)
C:0.12, Si:1.0, Mn:0.8, Ni:9.5, Cr:29.0
Mechanical Properties
min. 490 - Yield Strength (N/mm2)
600 - 800 - Tensile Strength (N/mm2)
min. 24 J - Impact Strength (ISO-V/+20ºC)
min. 20 - Elongation (Lo=5do)(%)
Welding Positions
2.50 x 250 - 60-80 amps
3.20 x 350 - 80-110 amps
Liability: Whilst all reasonable efforts have been made to ensure the accuracy of the information contained. This information is subject to change without notice and can be only considered as suitable for general guidance.
