Jasic DC TIG 180 - JT-180
The Jasic TIG 180 is a simple TIG welder aimed at the lower end of the professional market. For those who are looking for a no fuss TIG welder which is simple to work with and comes with the benefits of being quick and easy to setup.
This TIG welder runs on an IGBT inverter (like all Jasic inverters) which makes it generator friendly. Because of the superior build quality you also get a 2 year standard warranty and because you are buying it from Noz-alls, we register the warranty for you which increases it to a market leading 5 years.
Simple touches reflect the quality of this machine from a robust handle design to the rubberised case plastics - it really is a product you can feel confident in.
Key Features
HF start - longer tungsten life and easier arc striking.
MMA, TIG switch - two machines in one!
Down slope and post flow - no TIG crater at the end of your weld.
IGBT inverter - adapts to voltage change, generator friendly.
Single PCB design - improved reliability.
Technical Information
|
MMA |
TIG |
Input Voltage |
230v AC |
Input KvA |
7.1 |
5.2 |
Current Range |
10 - 160 Amps |
10 - 180 Amps |
Duty Cycle @ 40°C |
35% @ 180 Amps |
No Load Voltage |
60 |
65 |
Efficiency |
85% |
Power Factor |
0.7 |
Insulation Class |
IP21 S/F |
Dimensions (mm) |
365 x 135 x 227 |
Weight |
5.94 kg |
