Excalibur - Mixer Acetylene Type 3 / 5 Heavy Duty
Heavy Duty Acetylene mixer designed for high flow applications. HD mixer has a recessed seat and larger thread to prevent high flow nozzles being fitted to a standard mixer. HD DA mixer is for use with the AHT #25, #50 and #100 plus the single flame nozzles sizes #45, #55, #70 & #90.
Flame cleaning heads of all sizes 50mm through to 150mm wide.
Operating Safety
When the HD DA mixer is in use it is necessary to use a minimum of two standard industrial 8kg capacity acetylene cylinders so as to be able to provide sufficient and safe flow of acetylene gas without pulling off acetone from the cylinders.
The acetylene is dissolved into the acetone so the flow is always restricted to the rate of effervescence which is reduced as cylinders get smaller.
Pictures show the heavy duty acetylene mixer - necks and nozzle to suit this mixer must have the extended seat.
To aid identification a picture of all three types of mixer has been added.
