Jasic TIG 200 - JT-200
The Jasic TIG 200 is a simple TIG welder aimed at the user looking for a bit more power / higher duty cycle than the 180 version. It is quick and easy to use and also easy to setup - no fuss of the more intricate pulsed machines.
Thanks to the superior build quality you also get a 2 year standard warranty and because you are buying it from Noz-alls, we register the warranty for you which increases it to a market leading 5 years.
Simple touches reflect the quality of this machine from a robust handle design to the rubberised case plastics - it really is a product you can feel confident in.
Key Features
HF start - longer tungsten life and easier arc striking.
MMA, TIG switch - two machines in one!
Down slope and post flow - no TIG crater at the end of your weld.
IGBT inverter - adapts to voltage change, generator friendly.
Single PCB design - improved reliability.
Technical Information
| |
MMA |
TIG |
| Input Voltage |
230v AC |
| Input KvA |
8.2 |
6 |
| Current Range |
10 - 180 Amps |
10 - 200 Amps |
| Duty Cycle @ 40°C |
35% @ 200 Amps |
| No Load Voltage |
60 |
65 |
| Efficiency |
85% |
| Power Factor |
0.7 |
| Insulation Class |
IP21 S/F |
| Dimensions (mm) |
365 x 135 x 227 |
| Weight |
6.12 kg |
