Headux Elfin High Power 400Amp Industrial Stick Welder - 3 Phase Power Supply
The Headux 400 Amp stick welding inverter is a compact and relatively light weight stick welder weighing in at just 16kg (without the cables) which makes this welder much more user friendly when compared to a 400 Amp transformer stick welder.
The Headux inverter make use of the IGBT - transisitors ensuring this welder is very efficient, when you take the high power into account along with the compact size and weight then to that you add the fact that this machine has a 60% duty cycle running on maximum amperage (400 Amps measured at 40C) and you get a powerful tool which is going to help your projects get completed quicker and more easily with less fatigue.
As with all Headux welders the build quality is excellent and you can tell these machines are made of the right parts so you may have complete confidence in them.
A 3m set of leads are included as standard, we do have various electrode holder options depending on your preference.
Should you require longer leads, the welding cables we supply are made up by ourselves at Noz-Alls and we can supply any length required (within reason). We fit good quality earths and electrode holders so it will not be a token effort with some regrettable holder that you see supplied with many machines. When you would prefer an electrode holder and or work return lead of your choice please give Noz-Alls a call and we will make what you require. Tel 01242 681052.
Key Features
Self Adapting Arc Force - Less chance of sticking and lower levels of spatter
Anti-sticking function reduces welding current should a short circuit occur
Adjustable arc force enables optimum arc welding even with long cables.
Generator Friendly
Technical Information
Input Voltage |
AC 400v |
Fuse Rating |
40 |
Current Range |
30 - 400 Amps |
Duty Cycle @ 40°C |
60% @ 400 Amps |
No Load Voltage |
64 |
Insulation Class |
IP21 S/F |
Dimensions (LxWxH cm) |
49 x 24 x 41 (36 case) |
Weight |
15.8 kg |
